  • Optionally available as grating only or in combination with frame
  • Bespoke elements made to your specifications
  • Large selection of grating designs
  • Angle frames reinforced on the wall side or fully lined.
  • Frames fixed by screwing down or setting in concrete
  • Specified for various load classes
Angled frame with 7x7 mm longitudinal bar grating as light well cover
Angled frame with 7x7 mm longitudinal bar grating as light well cover
Angled frame with 20x3 mm longitudinal bar gratings made to measure
Angled frame with 20x3 mm longitudinal bar gratings made to measure
Wall-side reinforced angle frame with "Legato" design grating
Wall-side reinforced angle frame with "Legato" design grating
Wall-side reinforced angle frame with hot-dip galvanized mesh grating
Wall-side reinforced angle frame with hot-dip galvanized mesh grating
Fully lined angled frame with non-slip "Ritmo" grating
Fully lined angled frame with non-slip "Ritmo" grating
Fully lined angled frame with non-slip "Staccato" grating
Fully lined angled frame with non-slip "Staccato" grating
Vorschaubild: 1
Vorschaubild: 2
Vorschaubild: 3
Vorschaubild: 4
Vorschaubild: 5
Vorschaubild: 6
Request online

Receive a customized offer shortly

Our light-shaft covers are attractive closures designed to fit any cellar shaft perfectly. We make sure the cover fits perfectly because we manufacture each piece to your individual specifications. You make sure it looks the part by selecting the right style from our extensive grating range. There is something for every taste, from classic mesh gratings through to eye-catching design solutions.



Gratings and angle frames for any installation location

We offer a choice of suitable cellar-shaft covers, either as a grating manufactured to fit an existing angle frame, or as a complete package that includes both the grating and the angle frame. Additionally, we can reinforce the stainless-steel frames on the wall side or fully line them at the factory. Frames are fixed in place by screwing them down or setting them in concrete, depending on the variant.



Are your light shafts intended for areas that are driven over? No problem – we manufacture the covers in versions that can withstand pedestrians, cars or even trucks, depending on where you want to deploy them. Finishing touches to the product range include for instance the safety chains for the custom-made gratings.



Variant 1: Standard angle frame






Variant 2: Angled frame reinforced on the wall side






Variant 3: Angle frame fully relined




Light-shaft covers

Dimensions



custom-made product

Materials



Grating materials: stainless steel, hot-dip galvanised steel

Frame material: stainless steel

Material thickness



3.0mm to 6.0mm, depending on load

Info



Angle frames also available reinforced on the wall side or fully lined

Fixed by screwing down or setting in concrete

Accessories



Safety chains
